springboot整合activity自動部署及部署文件命名流程

問題描述

springboot整合activity，部署流程定義的時候在數據庫總是會自動的部署一次。

問題分析

查看啟動日志，出現如下一段話：

ProcessEngine default created

Process deployed: {id: myProcess_1:1:db6bacd7-edbd-11ea-b883-1860249fb796, key: myProcess_1, name: null }

在項目啟動的時候流程自動部署

查閱相關資料總結

1.項目中包含流程定義的xml或者bpmn文件，項目在第一次啟動的時候會自動部署。

解決方案

在配置文件中增加如下配置：

#項目隨著spring啟動自動部署
spring.activiti.check-process-definitions=false

刪除數據庫中部署的流程定義，再次啟動項目，沒有出現自動部署的現象。

Spring Boot集成Activiti工作流

項目搭建

pom.xml

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
	<modelVersion>4.0.0</modelVersion>
	<groupId>com.fengye.example</groupId>
	<artifactId>spring-boot-activiti</artifactId>
	<version>1.0-SNAPSHOT</version>
	<packaging>jar</packaging>
	<name>spring-boot-activiti</name>
	<description>Demo project for Spring Boot</description>
	<parent>
		<groupId>org.springframework.boot</groupId>
		<artifactId>spring-boot-starter-parent</artifactId>
		<version>1.3.0.RELEASE</version>
	</parent>
	<properties>
		<project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
		<java.version>1.8</java.version>
		<activiti.version>5.21.0</activiti.version>
	</properties>
	<dependencies>
		<dependency>
			<groupId>org.springframework.boot</groupId>
			<artifactId>spring-boot-starter-web</artifactId>
		</dependency>
		<dependency>
			<groupId>org.springframework.boot</groupId>
			<artifactId>spring-boot-starter-data-rest</artifactId>
		</dependency>
		<dependency>
			<groupId>org.springframework.boot</groupId>
			<artifactId>spring-boot-starter-data-jpa</artifactId>
		</dependency>
		<dependency>
			<groupId>mysql</groupId>
			<artifactId>mysql-connector-java</artifactId>
		</dependency>
		<dependency>
			<groupId>org.activiti</groupId>
			<artifactId>activiti-spring-boot-starter-basic</artifactId>
			<version>${activiti.version}</version>
		</dependency>
		<dependency>
			<groupId>org.springframework.boot</groupId>
			<artifactId>spring-boot-starter-test</artifactId>
			<scope>test</scope>
		</dependency>
	</dependencies>
	<build>
		<plugins>
			<plugin>
				<groupId>org.springframework.boot</groupId>
				<artifactId>spring-boot-maven-plugin</artifactId>
			</plugin>
		</plugins>
	</build>
</project>

application.properties配置

spring.jpa.hibernate.ddl-auto=update
spring.jpa.database=MYSQL
spring.datasource.url=jdbc:mysql://127.0.0.1:3307/spring-boot-activiti?characterEncoding=UTF-8
spring.datasource.username=root
spring.datasource.password=123456
spring.datasource.driver-class-name=com.mysql.jdbc.Driver

核心代碼

實體類

Person.java

package com.fengye.example.model;
import javax.persistence.Entity;
import javax.persistence.GeneratedValue;
import javax.persistence.Id;
import javax.persistence.ManyToOne;

/**
 * Created by jery on 2016/11/23.
 */
@Entity
public class Person {

	@Id
	@GeneratedValue
	private Long personId;

	private String personName;

	@ManyToOne(targetEntity = Comp.class)
	private Comp comp;

	public Person() {

	}

	public Person(String personName) {
		this.personName = personName;
	}

	public Long getPersonId() {
		return personId;
	}

	public void setPersonId(Long personId) {
		this.personId = personId;
	}

	public String getPersonName() {
		return personName;
	}

	public void setPersonName(String personName) {
		this.personName = personName;
	}

	public Comp getComp() {
		return comp;
	}

	public void setComp(Comp comp) {
		this.comp = comp;
	}
}

Comp.java

package com.fengye.example.model;
import javax.persistence.Entity;
import javax.persistence.GeneratedValue;
import javax.persistence.Id;
import javax.persistence.OneToMany;
import java.util.List;

/**
 * Created by jery on 2016/11/23.
 */

@Entity
public class Comp {
	@Id
	@GeneratedValue
	private Long compId;
	private String compName;
	@OneToMany(mappedBy = "comp", targetEntity = Person.class)
	private List<Person> people;
	public Comp(String compName)
	{this.compName = compName;}

	public Comp() {

	}

	public Long getCompId() {
		return compId;
	}

	public void setCompId(Long compId) {
		this.compId = compId;
	}

	public String getCompName() {
		return compName;
	}

	public void setCompName(String compName) {
		this.compName = compName;
	}

	public List<Person> getPeople() {
		return people;
	}

	public void setPeople(List<Person> people) {
		this.people = people;
	}
}

DAO

package com.fengye.example.dao;
import com.fengye.example.model.Person;
import org.springframework.data.jpa.repository.JpaRepository;
/**
 * Created by jery on 2016/11/23.
 */
public interface PersonRepository extends JpaRepository<Person, Long> {
	public Person findByPersonName(String personName);
}

package com.fengye.example.dao;
import com.fengye.example.model.Comp;
import org.springframework.data.jpa.repository.JpaRepository;
public interface CompRepository extends JpaRepository<Comp, Long> {
}

Activiti服務

package com.fengye.example.service;
import org.activiti.engine.RuntimeService;
import org.activiti.engine.TaskService;
import org.activiti.engine.task.Task;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;
import javax.transaction.Transactional;
import java.util.HashMap;
import java.util.List;
import java.util.Map;

/**
 * Created by jery on 2016/11/23.
 */

@Service
@Transactional
public class ActivitiService {
	//注入為我們自動配置好的服務
	@Autowired
	private RuntimeService runtimeService;
	@Autowired
	private TaskService taskService;

	//開始流程，傳入申請者的id以及公司的id
	public void startProcess(Long personId, Long compId) {
		Map<String, Object> variables = new HashMap<String, Object>();
		variables.put("personId", personId);
		variables.put("compId", compId);
		runtimeService.startProcessInstanceByKey("joinProcess", variables);
	}

	//獲得某個人的任務別表
	public List<Task> getTasks(String assignee) {
		return taskService.createTaskQuery().taskCandidateUser(assignee).list();
	}

	//完成任務
	public void completeTasks(Boolean joinApproved, String taskId) {
		Map<String, Object> taskVariables = new HashMap<String, Object>();
		taskVariables.put("joinApproved", joinApproved);
		taskService.complete(taskId, taskVariables);
	}
}

Service Task服務

package com.fengye.example.service;
import com.fengye.example.dao.CompRepository;
import com.fengye.example.dao.PersonRepository;
import com.fengye.example.model.Comp;
import com.fengye.example.model.Person;
import org.activiti.engine.delegate.DelegateExecution;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;
import java.util.Arrays;
import java.util.List;

/**
 * Created by jery on 2016/11/23.
 */
@Service
public class JoinService {
	@Autowired
	PersonRepository personRepository;
	@Autowired
	private CompRepository compRepository;

	//加入公司操作，可從DelegateExecution獲取流程中的變量
	public void joinGroup(DelegateExecution execution) {
		Boolean bool = (Boolean) execution.getVariable("joinApproved");
		if (bool) {
			Long personId = (Long) execution.getVariable("personId");
			Long compId = (Long) execution.getVariable("compId");
			Comp comp = compRepository.findOne(compId);
			Person person = personRepository.findOne(personId);
			person.setComp(comp);
			personRepository.save(person);
			System.out.println("加入組織成功");
		} else {
			System.out.println("加入組織失敗");
		}
	}

	//獲取符合條件的審批人，演示這里寫死，使用應用使用實際代碼
	public List<String> findUsers(DelegateExecution execution) {
		return Arrays.asList("admin", "wtr");
	}
}

控制器

package com.fengye.example.controller;
/**
 * Created by jery on 2016/11/23.
 */
import com.fengye.example.service.ActivitiService;
import org.activiti.engine.task.Task;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.*;
import java.util.ArrayList;
import java.util.List;

@RestController
public class MyRestController {
	@Autowired
	private ActivitiService myService;

	//開啟流程實例
	@RequestMapping(value = "/process/{personId}/{compId}", method = RequestMethod.GET)
	public void startProcessInstance(@PathVariable Long personId, @PathVariable Long compId) {
		myService.startProcess(personId, compId);
	}

	//獲取當前人的任務
	@RequestMapping(value = "/tasks", method = RequestMethod.GET)
	public List<TaskRepresentation> getTasks(@RequestParam String assignee) {
		List<Task> tasks = myService.getTasks(assignee);
		List<TaskRepresentation> dtos = new ArrayList<TaskRepresentation>();
		for (Task task : tasks) {
			dtos.add(new TaskRepresentation(task.getId(), task.getName()));
		}
		return dtos;
	}

	//完成任務
	@RequestMapping(value = "/complete/{joinApproved}/{taskId}", method = RequestMethod.GET)
	public String complete(@PathVariable Boolean joinApproved, @PathVariable String taskId) {
		myService.completeTasks(joinApproved, taskId);
		return "ok";
	}

	//Task的dto
	static class TaskRepresentation

	{
		private String id;
		private String name;

		public TaskRepresentation(String id, String name) {
			this.id = id;
			this.name = name;
		}

		public String getId() {
			return id;
		}

		public void setId(String id) {
			this.id = id;
		}

		public String getName() {
			return name;
		}

		public void setName(String name) {
			this.name = name;
		}
	}
}

入口類

import com.fengye.example.dao.CompRepository;
import com.fengye.example.dao.PersonRepository;
import com.fengye.example.model.Comp;
import com.fengye.example.model.Person;
import com.fengye.example.service.ActivitiService;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.boot.CommandLineRunner;
import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.boot.orm.jpa.EntityScan;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.ComponentScan;
import org.springframework.data.jpa.repository.config.EnableJpaRepositories;
/**
 * Created by jery on 2016/11/23.
 */
@SpringBootApplication
@ComponentScan("com.fengye.example")
@EnableJpaRepositories("com.fengye.example.dao")
@EntityScan("com.fengye.example.model")
public class ActivitiApplication {
   @Autowired
   private CompRepository compRepository;
   @Autowired
   private PersonRepository personRepository;
   public static void main(String[] args) {
      SpringApplication.run(ActivitiApplication.class, args);
   }

   //初始化模擬數據
   @Bean
   public CommandLineRunner init(final ActivitiService myService) {
      return new CommandLineRunner() {
         public void run(String... strings) throws Exception {
            if (personRepository.findAll().size() == 0) {
               personRepository.save(new Person("wtr"));
               personRepository.save(new Person("wyf"));
               personRepository.save(new Person("admin"));
            }
            if (compRepository.findAll().size() == 0) {
               Comp group = new Comp("great company");
               compRepository.save(group);
               Person admin = personRepository.findByPersonName("admin");
               Person wtr = personRepository.findByPersonName("wtr");
               admin.setComp(group); wtr.setComp(group);
               personRepository.save(admin); personRepository.save(wtr);
            }
         }
      };
   }
}
