Part1Redis 6.X Cluster 集群搭建
碼哥帶大家完成在 CentOS 7 中安裝 Redis 6.x 教程。在學習 Redis Cluster 集群之前，我們需要先搭建一套集群環境。機器有限，實現目標是一臺機器上搭建 6 個節點，構成一個三主三從集群模式。
1下載解壓
可直接到 Redis 官網下載最新穩定包，地址：https://redis.io/download。或者使用 命令：sudo wget http://download.redis.io/releases/redis-6.0.9.tar.gz 下載安裝包.。
碼哥統一把軟件包放在 /opt/soft 目錄下，并創建目錄 mkdir redisCluster用于放置集群配置文件。在 redisCluster 目錄下執行 mkdir 7000 7001 7002 7003 7004 7005 創建 6 個目錄分別對應每個節點 redis.conf 配置模板。
tar -zxf redis-6.0.9.tar.gz -C redisCluster 解壓到 redisCluster 目錄中。
2make 編譯
在編譯之前我們需要確認 gcc 版本，自 redis 6.0.0 之后，編譯 redis 需要支持 C11 特性，C11 特性在 4.9 中被引入。Centos 7 默認 gcc 版本為 4.8.5，所以需要升級gcc版本。
編譯錯誤
否則在編譯過程中會遇到如下錯誤日志：
- In file included from server.c:31:0:
- server.c:4999:59: error: ‘struct redisServer’ has no member named ‘cluster’
- (server.cluster_enabled && nodeIsMaster(server.cluster->myself)));
- ^
- cluster.h:58:27: note: in definition of macro ‘nodeIsMaster’
- #define nodeIsMaster(n) ((n)->flags & CLUSTER_NODE_MASTER)
- ^
- server.c: In function ‘main’:
- server.c:5047:11: error: ‘struct redisServer’ has no member named ‘sentinel_mode’
- server.sentinel_mode = checkForSentinelMode(argc,argv);
- ^
- server.c:5064:15: error: ‘struct redisServer’ has no member named ‘sentinel_mode’
- if (server.sentinel_mode) {
- ^
- server.c:5131:19: error: ‘struct redisServer’ has no member named ‘sentinel_mode’
- if (server.sentinel_mode && configfile && *configfile == '-') {
- ^
- server.c:5153:168: error: ‘struct redisServer’ has no member named ‘sentinel_mode’
- serverLog(LL_WARNING, "Warning: no config file specified, using the default config. In order to specify a config file use %s /path/to/%s.conf", argv[0], server.sentinel_mode ? "sentinel" : "redis");
- ^
- server.c:5158:11: error: ‘struct redisServer’ has no member named ‘supervised’
- server.supervised = redisIsSupervised(server.supervised_mode);
- ^
- server.c:5158:49: error: ‘struct redisServer’ has no member named ‘supervised_mode’
- server.supervised = redisIsSupervised(server.supervised_mode);
- ^
- server.c:5159:28: error: ‘struct redisServer’ has no member named ‘daemonize’
- int background = server.daemonize && !server.supervised;
- ^
- server.c:5159:49: error: ‘struct redisServer’ has no member named ‘supervised’
- int background = server.daemonize && !server.supervised;
- ^
- server.c:5163:29: error: ‘struct redisServer’ has no member named ‘pidfile’
- if (background || server.pidfile) createPidFile();
- ^
- server.c:5168:16: error: ‘struct redisServer’ has no member named ‘sentinel_mode’
- if (!server.sentinel_mode) {
- ^
- server.c:5178:19: error: ‘struct redisServer’ has no member named ‘cluster_enabled’
- if (server.cluster_enabled) {
- ^
- server.c:5186:19: error: ‘struct redisServer’ has no member named ‘ipfd_count’
- if (server.ipfd_count > 0 || server.tlsfd_count > 0)
- ^
- server.c:5186:44: error: ‘struct redisServer’ has no member named ‘tlsfd_count’
- if (server.ipfd_count > 0 || server.tlsfd_count > 0)
- ^
- server.c:5188:19: error: ‘struct redisServer’ has no member named ‘sofd’
- if (server.sofd > 0)
- ^
- server.c:5189:94: error: ‘struct redisServer’ has no member named ‘unixsocket’
- serverLog(LL_NOTICE,"The server is now ready to accept connections at %s", server.unixsocket);
- ^
- server.c:5190:19: error: ‘struct redisServer’ has no member named ‘supervised_mode’
- if (server.supervised_mode == SUPERVISED_SYSTEMD) {
- ^
- server.c:5191:24: error: ‘struct redisServer’ has no member named ‘masterhost’
- if (!server.masterhost) {
- ^
- server.c:5201:19: error: ‘struct redisServer’ has no member named ‘supervised_mode’
- if (server.supervised_mode == SUPERVISED_SYSTEMD) {
- ^
- server.c:5208:15: error: ‘struct redisServer’ has no member named ‘maxmemory’
- if (server.maxmemory > 0 && server.maxmemory < 1024*1024) {
- ^
- server.c:5208:39: error: ‘struct redisServer’ has no member named ‘maxmemory’
- if (server.maxmemory > 0 && server.maxmemory < 1024*1024) {
- ^
- server.c:5209:176: error: ‘struct redisServer’ has no member named ‘maxmemory’
- serverLog(LL_WARNING,"WARNING: You specified a maxmemory value that is less than 1MB (current value is %llu bytes). Are you sure this is what you really want?", server.maxmemory);
- ^
- server.c:5212:31: error: ‘struct redisServer’ has no member named ‘server_cpulist’
- redisSetCpuAffinity(server.server_cpulist);
- ^
- server.c: In function ‘hasActiveChildProcess’:
- server.c:1480:1: warning: control reaches end of non-void function [-Wreturn-type]
- }
- ^
- server.c: In function ‘allPersistenceDisabled’:
- server.c:1486:1: warning: control reaches end of non-void function [-Wreturn-type]
- }
- ^
- server.c: In function ‘writeCommandsDeniedByDiskError’:
- server.c:3826:1: warning: control reaches end of non-void function [-Wreturn-type]
- }
- ^
- server.c: In function ‘iAmMaster’:
- server.c:5000:1: warning: control reaches end of non-void function [-Wreturn-type]
- }
- ^
- ....
解決方式
- yum -y install gcc gcc-c++ make tcl
- yum -y install centos-release-scl
- yum -y install devtoolset-9-gcc devtoolset-9-gcc-c++ devtoolset-9-binutils
- scl enable devtoolset-9 bash
升級之后便可解決 make 報錯問題。
注意：scl命令啟用只是臨時的，退出xshell或者重啟就會恢復到原來的gcc版本。如果要長期生效的話，執行如下 sudo echo "source /opt/rh/devtoolset-9/enable" >>/etc/profile。
cd /opt/soft/redisCluster/redis-6.0.9 切換到目錄執行 make 。
編譯完成使用 make install 對 redis 進行安裝 ，命令：sudo make install。
3修改配置文件
cd /opt/soft/redisCluster/redis-6.0.9 將 redis.conf 分別復制到 7000 7001 7002 7003 7004 目錄中。
分別修改 6 個 redis.conf
- ## 7000-7005端口
- port 7000
- ## 后臺啟動
- daemonize yes
- ## 如果是在單機模擬集群必須指定bind的IP，如果不修改ip的話使用程序連接集群會報錯
- bind 192.168.221.150
- ## 開啟redis-cluster集群
- cluster-enabled yes
- ## 每個實例還包含存儲此節點配置的文件的路徑，默認情況下為nodes.conf，自動創建
- cluster-config-file nodes_7000.conf
- ## 超時
- cluster-node-timeout 500
- ## 開啟aof
- appendonly yes
- #注釋cluster集群下不允許復制。
- #replicaof 127.0.0.1 9000
- #關閉保護模式,如果開啟需要設置密碼，比較繁瑣，可根據自己的需求來
- protected-mode no
每個配置文件只需要修改 port 和 cluster-config-file 就可以了。
4啟動節點并創建集群
啟動節點
進入 redisCluster 目錄，執行指令依次啟動每個節點。redis-6.0.9/src/redis-server 700x/redis.conf 注意指定每個節點配置文件，如果不指定配置文件會默認使用src下的配置。
創建集群
進入任意一個節點，執行以下指令創建集群
指令如下：
- redis-6.0.9/src/redis-cli --cluster create 172.16.90.152:7000 172.16.90.152:7001 172.16.90.152:7002 172.16.90.152:7003 172.16.90.152:7004 172.16.90.152:7005 --cluster-replicas 1
集群參數解釋：
- cluster-replicas 1：表示希望為集群中的每個主節點創建一個從節點(一主一從)。
- cluster-replicas 2：表示希望為集群中的每個主節點創建兩個從節點(一主二從)。
控制臺響應：
- >>> Performing hash slots allocation on 6 nodes...
- Master[0] -> Slots 0 - 5460
- Master[1] -> Slots 5461 - 10922
- Master[2] -> Slots 10923 - 16383
- Adding replica 172.16.90.152:7004 to 172.16.90.152:7000
- Adding replica 172.16.90.152:7005 to 172.16.90.152:7001
- Adding replica 172.16.90.152:7003 to 172.16.90.152:7002
- >>> Trying to optimize slaves allocation for anti-affinity
- [WARNING] Some slaves are in the same host as their master
- M: 06c56f5a6a4436108fae931be499465985141d39 172.16.90.152:7000
- slots:[0-5460] (5461 slots) master
- M: 0ab7c9efd97319d94a8ea52452ec58f7708d812d 172.16.90.152:7001
- slots:[5461-10922] (5462 slots) master
- M: 096f076d99363270c02785a2fb298e2ee65d3f07 172.16.90.152:7002
- slots:[10923-16383] (5461 slots) master
- S: 69d621060295eb433af3e34e702142df0fd4d73d 172.16.90.152:7003
- replicates 06c56f5a6a4436108fae931be499465985141d39
- S: 1d37df0aa0e2310aedb5a380f95cc818256003f8 172.16.90.152:7004
- replicates 0ab7c9efd97319d94a8ea52452ec58f7708d812d
- S: d9204f6da875a4b2522c5fa25d9e6c1f95cf51ea 172.16.90.152:7005
- replicates 096f076d99363270c02785a2fb298e2ee65d3f07
- Can I set the above configuration? (type 'yes' to accept):
Can I set the above configuration? (type 'yes' to accept): 詢問是否確認節點 slots 分配方案， 我們輸入 ‘yes’。
- >>> Nodes configuration updated
- >>> Assign a different config epoch to each node
- >>> Sending CLUSTER MEET messages to join the cluster
- Waiting for the cluster to join
- .
- >>> Performing Cluster Check (using node 172.16.90.152:7000)
- M: 06c56f5a6a4436108fae931be499465985141d39 172.16.90.152:7000
- slots:[0-5460] (5461 slots) master
- 1 additional replica(s)
- S: 1d37df0aa0e2310aedb5a380f95cc818256003f8 172.16.90.152:7004
- slots: (0 slots) slave
- replicates 0ab7c9efd97319d94a8ea52452ec58f7708d812d
- M: 0ab7c9efd97319d94a8ea52452ec58f7708d812d 172.16.90.152:7001
- slots:[5461-10922] (5462 slots) master
- 1 additional replica(s)
- S: d9204f6da875a4b2522c5fa25d9e6c1f95cf51ea 172.16.90.152:7005
- slots: (0 slots) slave
- replicates 096f076d99363270c02785a2fb298e2ee65d3f07
- S: 69d621060295eb433af3e34e702142df0fd4d73d 172.16.90.152:7003
- slots: (0 slots) slave
- replicates 06c56f5a6a4436108fae931be499465985141d39
- M: 096f076d99363270c02785a2fb298e2ee65d3f07 172.16.90.152:7002
- slots:[10923-16383] (5461 slots) master
- 1 additional replica(s)
- [OK] All nodes agree about slots configuration.
- >>> Check for open slots...
- >>> Check slots coverage...
- [OK] All 16384 slots covered.
[OK] All 16384 slots covered.
到此完成!
5查看集群狀態
redis-6.0.9/src/redis-cli --cluster check 172.16.90.152:7000
6注意事項
當使用 redis-6.0.9/src/redis-cli --cluster create 172.16.90.152:7000 172.16.90.152:7001 172.16.90.152:7002 172.16.90.152:7003 172.16.90.152:7004 172.16.90.152:7005 --cluster-replicas 1 創建集群以后，一次創建，永久使用。之后直接啟動每個節點即可構建集群。
結束命令：redis-6.0.9/src/redis-cli -c -h 192.168.124.23 -p 7004 shutdown
進入集群命令 redis-cli -c -h host -p prot 不帶-c 參數進入的不是集群
搭建好集群后，期待下一篇「Redis 高可用篇：Cluster 能支持的數據有多大?」
